Ceramic Strip Heaters are constructed of specially selected high quality materials, beginning with the high temperature alloy resistance wire uniformly coiled and spaced over the width of the heated length of the strip heater. This controlled coil process and replacement assures uniform heat distribution over the entire active surface of the heater. Special care is taken to secure the stud-type terminal to the high-temperature alloy resistance contact.
The coiled resistance wire is embedded in a special refractory Material that possesses excellent heat transfer characteristics and superior insulation properties. The entire heater assembly is encased in either stainless or chrome steel sheath and is compressed under high pressure. The completed assembly is heated under controlled conditions to bake and semi vitrify the refractory for a rigid, vibration resistant, heavy-duty heating unit.
Finned Strip Heater can be finned to improve heat transfer. The fins are specially designed to provide maximum surface contact for good heat dissipation into the finned cross sections, thus resulting in rapid heat transfer to the air.
| SPECIFICATIONS FOR CERAMIC STRIP HEATER |
|||
|
Ceramic Strip Heaters
|
Item No. | PM-CSH | |
| Wattage | Customized | ||
| Voltage | 24-480 V | ||
| Working Temperature | Intermittent operating max. temp | 800°C) | |
| Continuous operating temp | 550°C | ||
|
Dimension
|
Section size: | 11 x 38mm | |
| section size tolerance | -0.1mm to -1mm | ||
| Length tolerance | +/- 1 mm | ||
Main Features
|
1) High heat transfer rates and fast heat up |
|
|
2) Ceramic construction for higher temperatures |
|
|
3) Long life |
|
|
4) Large selection of lengths, sizes and terminations |
|
|
5) Low expansion characteristics |
|
|
6) 3-Phase available |
|
|
7) Distributed wattage available |
 |
Ceramic Strip HeaterName: strip heater / ceramic strip heater / finned strip heater / ceramic finned strip heater Brand: PAMAENS Material: 1. Cr20Ni80, high quality Swedish resistance wire is available 2. Ceramic insulator 3. SS304 / SS316 / INCOLOY 4. Nylon,metal braided,fiberglass ,silicone rubber, kevlar, fiber glass wire with stainless steel protection tube |
 |
Strip Heater (Unpolished)Name: ceramic strip heater Length could be customized |
 |
Strip Heater (polished)Name: ceramic strip heater Length could be customized |
Pre-Sales Service
- Flexible MOQ
- Fast and on-time delivery (normally within 15 days)
- Free replacement if any quality issues within guarantee period.
- After-sale services
- OEM and ODM service
After-Sales Service
PAMAENS has strict quality control system on material sourcing, manufacturing processing, and products testing. We insist on using high quality raw material and inspect all the materials we will use. We do 100% product testing before shipping, the test includes x-ray inspection, rated power and voltage testing, cold insulation resistance test, leakage testing, pressure test, surface temperature uniformity and various electrical testing.
We provide one year warranty for most of our products, free replacements or refund could be applied if our customers have any quality problem within one year.
