Drum Heated Jacket

Short Description:

Drum Heated Jackets are designed to provide practical and efficient means of freeze protection, viscosity control, and ease of maintenance in elevated temperatures, which come with adjustable Velcro straps or straps with clips to ensure proper fit of larger and smaller 55 gallon drums/barrels. Wrapping the blanket around the entire drum ensures rapid and even heating. The digital thermostat with timer ensures consistent heating which will prevent under and overheating your material.

FOB Price: US $150-300 / Piece

Min.Order Quantity: 2 Piece/Pieces

Supply Ability: 1000 Pieces per Month

Shipping: Express, ocean shipping, air shipping

Payment Terms: T/T, PAYPAL, WESTERN UNION

Production time: 7-15 days

Send email to us Download as PDF

Product Detail

Product Tags

Specification
Item Name	Drum Heated Jacket
Item No.	PM-DHJ
Voltage	90-250v / One phase, 380v / three phases
Wattage	Customized
Wattage density	100w-3000w per square meter
Dimensions	1884 X 860 mm (Could be customized)
Max. Operation Temp:	260 Deg C or 500 Deg F
Min. Operation Temp:	-50 Deg C or -58 Deg F
Standard Thickness	5-30mm
Certificates	CE
Packaging	Carton box / Fumigation free wooden cas
Color	Grey / Black / Blue
Material
Internal layer	Silicone coated glass fiber cloth / Oxford cloth
Middle layer	High quality heating wire and aramid fiber (AFRP) insulation
External layer	Silicone coated glass fiber cloth / glass fiber reinforced aluminum cloth
Accessories Information
Temperature control	Digital / 0-190 deg C, Mechnical 0-150 deg C
Power cord	one to three meters with customized plug
Insulation cover for lip	Optional
Introductions of Drum Heated Jacket
Drum Heated Jackets are designed to provide practical and efficient means of freeze protection, viscosity control, and ease of maintenance in elevated temperatures, which come with adjustable Velcro straps or straps with clips to ensure proper fit of larger and smaller 55 gallon drums/barrels. Wrapping the blanket around the entire drum ensures rapid and even heating. The digital thermostat with timer ensures consistent heating which will prevent under and overheating your material. The blanket heater is high in energy savings when compared to a traditional silicon band heater since it insulates the entire drum and ensures minimal heat loss.
The feature of Drum Heated Jacket
A.Thickened the thermal insulation layer make the heating blanket has better thermal insulation, and faster heating up.
B. Smoothly lied resistant wire makes the heating blanket heating Uniform.
C. High temperature resistance flame retardant fabrics are used.
D. The heating blanket is designed with connection and fixation device, by which the heating area could extend easily.
E. Different with insulation surface, the temperature tolerance of heating surface is more than 260℃.
F. The heating blanket is built in temperature control in case of burning of the heating blanket by abnormal use.
G. Several temperature probes are layout uniformly, making sure the uniform heating.
Advantages of Drum Heated Jacket
1. Integrated type
2. Custom size and shape
3. Full coverage heating and insulation, high thermal and heating efficiency
4. Good flexibility
5. Uniform heating
6. Built-in overheat switch to prevent accidental burning of heated body
7. Large range, high power, fast heating.
8. High insulation performance of all material
9. Easy to install and remove, safer and adjustable
RFQ
1. Dimension of the drum
2. Voltage & Wattage
3. What kind of material inside the tank
4. What’s the initial temperature of the material
5. What’s the target temperature of the material
6. Plug type (optional)
7. Quantity
